Kasuga Electric Co., Ltd. Push button switch for direct operation of electric motor COB261T COB261T 1 unit

Catalogue number: COB261T Features: ● Push button switch for directly operating an electric motor. ● Protection class: IP65 (JIS C 0920). ● Compliant with the Electrical Appliance and Material Safety Act. Applications: ● Push button switch for directly operating an electric motor. Specifications: ● Number of buttons: 2 ● Button characters: Up, Down ● Maximum applicable motor capacity: Three-phase 200V/220V-1kW ● Length (mm): 69 ● Width (mm): 123 ● Height (mm): 49 ● Terminal screw: M3.5 (crimp terminal type) ● Compatible wire (［［MM2］］): 2 ● Included character plate: Up, Down ● Contact configuration 2a-2a Material/Finish: ● ABS resin (equivalent to 7.5YR7/13)
