Kasuga Electric Co., Ltd. Push button switch for indirect operation of electric motors COB61 COB61 1 unit

Catalogue number: COB61 Features: ● Push button switch operated via an electromagnetic switch. ● Protection class IP65 (JIS C 0920). ● Compliant with the Electrical Appliance and Material Safety Act. Applications: ● Push button switch for operating an electromagnetic switch. Specifications: ● Number of buttons: 2 ● Button characters: Up, Down ● Length (mm): 69 ● Width (mm): 123 ● Height (mm): 49 ● Rating: AC250V-5A ● Contact configuration 1a-1a Material/Finish: ● ABS resin (equivalent to 7.5YR7/13)
