Tsubakimoto Chain Shock Relay ED Series TSB020ED 1 unit

Catalog number: TSB020ED Features: ● Current monitoring control device that quickly detects overcurrent when the motor is overloaded and prevents damage to the equipment. ● Motor current value and various setting values ​​during operation can be displayed digitally. ● Compact with integrated CT. Applications: ● Lifting equipment and conveyors. Specifications: ● Suitable motor capacity (kW) 200V class: 0.1/0.2 ● Suitable motor capacity (kW) 400V class: 0.1, 0.2/0.4, 0.75 ● Current setting range (A): 0.2. to 1.20/0.4 to 2.40 ● Contact configuration: 1a1b ● Contact rating: 3A, 250VAC (cosθ=1) ● Length (mm): 70.8 ● Width (mm): 60.2 ● Height (mm): 70.5 ● Current setting range T2 (A ): 0.2 to 1.2 ● Current setting range T1 (A): 0.4 to 2.4 ● Detection current frequency: 20 to 200 Hz ● Maximum motor circuit voltage: AC600V 50/60Hz ● Start time: 0.2 to 10.0 seconds (in 0.2 second increments), shock time: 0.2 to 5.0 seconds (in 0.2 second increments) ● Power consumption: 2.0W or less ● CT penetration number selection switch type (T1/T2) ● UL/cUL certified product ● CCC certified product
