Tsubakimoto Chain Shock Relay ED Series TSB550ED 1 unit

Catalog number: TSB550ED Features: ● Current monitoring control device that quickly detects overcurrent when the motor is overloaded and prevents damage to the equipment. ● Motor current value and various setting values ​​during operation can be displayed digitally. ● Compact with integrated CT. Applications: ● Lifting equipment and conveyors. Specifications: ● Suitable motor capacity (kW) 200V class: 3.7/5.5 ● Suitable motor capacity (kW) 400V class: 7.5/11 ● Current setting range (A): 6.00-26.0/9.00-34.0 ● Contact configuration: 1a1b ● Contact rating: 3A, 250VAC (cosθ=1) ● Length (mm): 70.8 ● Width (mm): 60.2 ● Height (mm): 70.5 ● Current setting range T2 (A): 6 .0-26●Current setting range T1 (A): 9.0-34●Detection current frequency: 20-200Hz●Maximum motor circuit voltage: AC600V50/60Hz●Start time: 0.2-10.0 seconds (in 0.2 second increments), shock time: 0.2-5.0 seconds (in 0.2 second increments)●Power consumption: 2.0W or less●CT penetration number selection switch type (T1/T2)●UL/cUL certified●CCC certified
