Submersible high-spin pump, diameter 50mm, single-phase 100V, 0.48kW, lift height 8m, LB-480A-62, 1 unit

The LB type boasts reliability and proven performance. The use of a high-spin impeller with a high gap structure makes the impeller resistant to wear, and even if it does wear, there is little degradation in performance. The design is less likely to lock up due to sand, etc. The discharge direction can be changed to "up" or "side", and the hose will not bend when pulled sideways. It can be removed by simply loosening the cap nut. By using carefully selected wear-resistant composite materials, we have achieved a lightweight and compact design that is roughly the same size as an A4 sheet of paper (0.25kW/0.48kW). The pump section can be disassembled with just one box wrench, making maintenance easier. Electrode type automatic type (LBA type). Simply connect the power supply for automatic operation. A completely new control method is used to prevent noise caused by continuous dry operation. Highly sensitive electrodes for liquid level detection Furthermore, the automatic operation system is combined with a timer function to prevent malfunctions due to rough water waves, making it particularly effective for use in residential areas at night. When the water level rises and both electrodes are submerged in water, the pump starts, and when the water level drops and the water surface separates from the electrodes, the timer starts and the pump stops after about 1 minute of operation. Discharge diameter (mm): 50 Output (kW): 0.48 Phase voltage (V): Single phase 100 Total head (m): 8 Discharge volume (m3/min): 0.12 Starting method: Capacitor operation Mass (kg): 11 Foreign object passage diameter (mm): 6 Cabtyre cable material: VCT Cabtyre cable core count x cross-sectional area (mm2): 3 x 1.25 Cabtyre cable finished outer diameter (mm): 10.1 Cabtyre cable length (m): 5
