When moisture is detected, the LED will turn red and a buzzer will sound.
By connecting the LT-109, the AC100V output can be turned ON/OFF in sync with moisture detection (can be switched between normal ON and normal OFF).
Size: 185 x 229 x 98mm (excluding rubber feet)
Indicator light: Sensor status indicator light (3 places) / Power indicator light
Sensor connection ports: 3 locations
Output: Buzzer sound (ON/OFF switching), relay contact (AC100V/3A, DC30V/3A)
Power supply: AC100V 50/60Hz 0.3A
Power cord length: 1.8m
Accessories: 1 leak sensor, AC adapter (DC15V)
<Sensor section>
Material: Body: PP (polypropylene), Cable: PVC (polyvinyl chloride resin)
Applicable medium: Water
Cable length: 2m
*Do not use in an atmosphere containing corrosive gases, etc.
