Junkosha Brass Fitting (Millimeter Series) S Sleeve 4mm S-04 1 pc

Catalog number: S-04 Features: ● Requires replacement every time it is removed. Applications: ● For pneumatic piping ● For hydraulic piping ● For hydraulic piping Specifications: ● Compatible tube outer diameter (mm): 4 ● Fluid used: air, water, oil, organic solvents ● Compatible tube outer diameter D (mm): 4 ● Fluid used: air, water, oil, organic solvents ● Fluid temperature: -20 to 60°C (air), 0 to 60°C (water), -20 to 60°C (oil), -20 to 60°C (organic solvents) ● Maximum operating pressure: Complies with maximum operating pressure for tubes ● Vacuum pressure used: 0.014 kPa or more (excluding US, when the fluid used is air) ● Applicable tubes (when the fluid used is air): Nylon tubes (AS1, AS2, AS4), Spot welding equipment tubes (SP4, SPF), Polyurethane tubes (US, UH, UF, UFL, UE, UC), Multilayer tubes (AP1, AP4, UP1) ● Applicable tubes (when the fluid used is water): Nylon tubes (AS1, AS2, AS4), Spot welding equipment tubes ( SP4, SPF), Polyurethane Tube (UF, UFL), Multi-layer Tube (AP1, AP4, UP1) ●Applicable Tube (When the fluid used is oil): Nylon Tube (AS1, AS2, AS4), Multi-layer Tube (AP1, AP4, UP1) ●Applicable Tube (When the fluid used is organic solvent): Multi-layer Tube (AP1, AP4, UP1) Material/Finish: ●Nylon Caution: ●Do not freeze. ●When using tubes other than those applicable, the outer diameter precision should be within ±0.1mm for nylon and within ±0.15mm for urethane, and the roundness should be within 0.2mm (maximum outer diameter - minimum outer diameter).
