DC stabilized power supply (wide range) PSW-1080L80 1 piece

This is a switching type DC stabilized power supply that is capable of a wide range of voltage and current output within the maximum rated power. We offer a total of 15 models with three output capacities (360W/720W/1080W) and five maximum voltage types (30V/80V/160V/250V/800V) to suit a wide range of applications. It comes standard with USB and LAN ports and is also rack-mountable, so it can also be used as a system power supply. It also complies with CE marking and the European RoHS Directive. Size (mm): 214 x 350 x 124 Output voltage: 1080W Output current: 0-40.5A Rated power: 0-80V Output current: 0-80V/0-40.5A/1080W Display and output range: Voltage 10mV~ / Current 10m~A / Power 10W~ (Wide range of voltage and current settings possible within the rated power range) Various functions: Test mode, output slew rate setting, variable internal resistance, CC/CV priority mode, bleeder circuit ON/OFF Master-slave operation: Parallel connection/3 units of the same model, Series connection (excluding 250V and 800V models)/2 units of the same model Interface: External analog control, LAN (Ethernet) port, USB host/device port, GP-IB (optional)/GUG-001 (GP-IB-USB converter), RS-232C (optional) Power supply voltage: AC100-240V/50-60Hz worldwide compatible (however, the standard power cord is for AC100V only)
