Kakuta Toggle Clamp (Downward Pressing Type) Cam Clamp No. 130 Clamping Pressure 2.5kN KC-130 1 pc

Catalogue number: KC-130 Features: ●One-touch operation, no adjustment required. Even for workpieces with a large variation of ±1.5 mm, a constant pressure is applied without adjusting the pressure bolt. Specifications: ●Total length (mm): 220 ●Tightening pressure (kN): 2.5 ●Attached bolt diameter: M8 x 50 ●Clamp arm movement angle (°): 70 ●Handle operation angle (°): 165 ●Installation method: Flange base ●Product marking: No. 130 ●Downward pressing type ●Flange base Material/Finish: ●Steel (SPCC)
