Kakuta Horizontal Handle Toggle Clamp (Downward Pressing Type) No. 38P Small Clamping Pressure 2.8kN KC-38P-S 1 pc

Catalog number: KC-38P-S Features: ●The clamp mounting base is a side-mounted type. ●Comes with a release lever. Specifications: ●Total length (mm): 221 ●Tightening force (kN): 2.8 ●Attached bolt diameter: M6 x 40 ●Clamp arm movement angle (°): 85 ●Handle operation angle (°): 73 ●Product marking: No. 38P small ●Tightening force (kn): 2.8 ●Downward pressing type ●Horizontal handle ●Side mounting Material/Finish: ●Steel (SPCC) Caution: ●The indicated tightening force is a guideline. ●The tightening force becomes weaker toward the tip of the clamp arm. ●Please note that impact, vibration, and internal pressure may cause damage. ●Be careful not to get your hand caught.
