Kakuta Horizontal Handle Toggle Clamp (Downward Pressing Type) No. HH451B Clamping Pressure 2.4kN KC-HH451B 1 pc

Catalog number: KC-HH451B Features: ●Comes with rubber-attached BT. Specifications: ●Total length (mm): 175 ●Tightening force (kN): 2.4 ●Attached bolt diameter: M8×50 (RBT-8) ●Clamp arm movement angle (°): 90 ●Handle operation angle (°): 60 ●Product marking: HH451-B ●Remarks: △ ●Tightening force (kg): 240 ●Downward pressure type ●Horizontal handle type ●Straight base Material/Finish: ●Steel (SPCC) Set contents/Accessories: ●M8×49 Rubber-attached bolt (RBT-8) ●2 nuts ●2 washers Caution: ●The indicated tightening force is a guide. ●The tightening force becomes weaker toward the tip of the clamp arm. ●Please note that impact, vibration, and internal pressure may cause damage. ●Be careful not to pinch your hand.
