Kakuta Handle Vertical Toggle Clamp No. HV350 KC-HV350 1 pc

Catalog number: KC-HV350 Features: ●This clamp comes with a set of rubber-attached bolts. ●This clamp comes with a set of rubber-attached BTs. *Excluding HV150 Specifications: ●Total length (mm): 145 ●Tightening pressure (kN): 2.25 ●Attached bolt diameter: M8×50 (RBT-8) ●Clamp arm movement angle (°): 100 ●Handle operation angle (°): 60 ●Product marking: No. HV350 ●Mounting pitch (mm): 19.0 ●Remarks: * ●Downward pressing type ●Vertical handle ●Flange base Material/Finish: ●Steel (SPCC) ●Screw tip rubber: Nitrile rubber Caution: ●Welding is required when installing the bolts.
