Recording timer TI-9A 121-588 1 unit

This is a discharge recording type timer with low contact friction. By minimizing contact friction with the tape, measurement errors are prevented as much as possible. Discharge recording can be switched between three levels: 10/50/100Hz. By using the included support rod, it can be easily fixed to an iron stand, etc. The specially shaped electrodes allow for not only small dots, but also long, easy-to-read lines of discharge records. This is convenient for measuring the length by placing a ruler or similar object against the line. If the discharge point is no longer visible After a long period of use, tape residue may accumulate on the discharge electrode, making the discharge point unclear. In this case, cut the included 250-600 grit sandpaper into a strip the same width as the recording tape (1.5 cm) and run it through the electrode tip to polish it and restore it. Recording method: Discharge type Dot interval: 1/10, 1/50, 1/100 seconds Dotting method: dots and lines Recording medium: Low-voltage discharge recording tape Power supply: AC100V AC adapter Size: Approx. W105 x D105 x H35mm Weight: Approx. 200g Accessories: C-clamp discharge recording tape (width 15mm x length 40m), sandpaper Product code: 121-588
