Since it is a self-priming type, there is no need for priming water and it can be operated immediately with just one touch.
Electromagnetically driven diaphragm pump. Model number: WDP-1
Fluid used: Liquid
Usable liquid viscosity: approx. 300cSt or less
Operating temperature: -10 to 60°C
Nozzle: Inner diameter: Approx. φ5mm, Outer diameter: Approx. φ8mm
Wetted parts material: Nozzle/PMP (polymethylpentene), Case/PP (polypropylene), O-ring/silicon rubber
Power supply: AC100V 30W
Size: 130 x 50 x 55 mm
Weight: 500g
Accessories: Power cord (plug type: 2P), silicone tube (φ7 x φ10) 2m, hose bands x 4
Flow rate: 1000mL/min
Maximum discharge pressure: 0.03MPa
RoHS2 (EU)2015/863 compliant [About RoHS]
