Nagano Compact pressure gauge Pressure range (MPa): 0 to 0.4 GK25-161-0.4MP 1 unit

Catalog number: GK25-161-0.4MP Features: ●This pressure gauge is used for measuring the pressure of small equipment or pneumatic equipment, and helps to miniaturize the entire equipment. ●It is small and lightweight, so it is convenient for places with limited installation space. Specifications: ●Pressure range (MPa): 0 to 0.4 ●Minimum scale (MPa): 0.020 ●Accuracy: ±3% FS ●Connection size: R1/8 ●Case shape: D ●Size: 40mm ●JIS compliant Material/Finish: ●Bourdon tube: brass ●Stud: brass Note: ●Please check the thread size, thread shape (G thread or R thread), and pressure range (MPa) before ordering.
