Nagano Compact pressure gauge Pressure range (MPa): 0 to 2.0 GK25-271-2.0MP 1 unit

Catalog number: GK25-271-2.0MP Features: ●This pressure gauge is used for measuring the pressure of small equipment or pneumatic equipment, and helps to miniaturize the entire equipment. Specifications: ●Pressure range (MPa): 0 to 2.0 ●Minimum scale (MPa): 0.100 ●Accuracy: ±3% FS ●Connection size: R1/4 ●Case shape: D ●Size: 50mm ●JIS compliant Material/Finish: ●Bourdon tube: brass ●Stud: brass Note: ●Please check the thread size, thread shape (G thread or R thread), and pressure range (MPa) before ordering.
