Nagano Small Pressure Gauge GK20-271-0.2MP 1 pc

Catalog number: GK20-271-0.2MP Features: ●This pressure gauge is used for measuring the pressure of small equipment or pneumatic equipment, and helps to miniaturize the entire equipment. Specifications: ●Pressure range (MPa): 0 to 0.2 ●Minimum scale (MPa): 0.010 ●Accuracy: ±3% FS ●Connection size: R1/4 (PT) ●Case shape: A ●Size: 50mm ●JIS compliant Material/Finish: ●Bourdon tube: brass ●Stud: brass Note: ●Please check the thread size, thread shape (G thread or R thread), and pressure range (MPa) before ordering.
