Nagano JIS general-purpose pressure gauge A frame (tapered) Pressure range (MPa): 0.0 to 4.00 GS50-171-4.0MP 1 unit

Catalog number: GS50-171-4.0MP Features: ●This pressure gauge has a structure that transmits the elastic deformation (movement) of the Bourdon tube to the pointer, and is easy to handle due to its simple structure. ●It is a JIS B 7505-1 standard product. Specifications: ●Pressure range (MPa): 0.0 to 4.00 ●Minimum scale (MPa): 0.100 ●Accuracy: ±1.6% FS ●Case shape: A ●Connection size: R1/4 ●Size (mm): 60 ●Size (mm): 60 ●JIS standard product: ATR1/4 Material/Finish: ●Bourdon tube: brass, stainless steel (SUS316) for pressure ranges of 4MPa or more ●Stud: brass Note: ●Please check the thread size, thread shape (G thread or R thread), and pressure range (MPa) before ordering.
