High Frequency Paratip Holder PTH40R 1 piece

Catalog number: PTH40R Features: ● No need for sharpening, shaping, or grinding, so it can be used immediately. ● The specially shaped tip eliminates chatter during cutting. ● TIN coating significantly improves wear resistance, heat resistance, and chipping resistance, significantly increasing tool life by 3 to 10 times. Applications: ● Holder for lathe processing. ● For parting and grooving. Specifications: ● Width (mm): 16 ● Height (mm): 25 ● Total length (mm): 170 ● Compatible tip: Paratip 40 type ● Maximum diameter of round bar (mm): 28.5 ● Maximum diameter of pipe: Diameter 50 mm, thickness 11.0 mm Diameter 100 mm, thickness 9.0 mm Material/Finish: ● Carbon steel for mechanical construction
