High frequency paratip holder PTH30R 1 piece

Catalog number: PTH30R Features: ● No need for sharpening, shaping, or grinding, so it can be used immediately. ● The specially shaped tip eliminates vibration during cutting. ● TIN coating significantly improves wear resistance, heat resistance, and chipping resistance, significantly increasing tool life by 3 to 10 times. Applications: ● Holder for lathe processing. ● For parting and grooving. Specifications: ● Width (mm): 15 ● Height (mm): 19 ● Total length (mm): 150 ● Compatible tip: Paratip 30 type ● Maximum diameter of round bar (mm): 21 ● Maximum diameter of pipe: Diameter 50 mm, thickness 7.4 mm Diameter 100 mm, thickness 6.0 mm Material/Finish: ● Carbon steel for mechanical construction
