3M Vinyl Tape 117S Black 19mm x 20m 117S BLA 20 1 roll

Catalogue number: 117S BLA 20 Features: ● Vinyl tape with a slightly hard base material. ● Lead-free type. ● High adhesive strength ensures firm adhesion. ● Can be cut by hand. ● Safe as it is a lead-free product (no intentional inclusion) Applications: ● Primary electrical insulation up to 600V in electrical wiring work. ● Bundling and fixing various wiring and piping. ● Bundling, fixing and color-coding wiring, piping, wire harnesses, etc. ● Protects connections from UV rays (for outdoor use) ● For insulating coating of internal wiring in machines, etc. Specifications: ●Color: Black ●Width (mm): 19 ●Length (m): 20 ●Thickness (mm): 0.2 ●Adhesive strength (N/10mm): 1.1 ●Tensile strength (N/10mm): 34 ●Operating temperature range (℃): -10 to 90 ●Compliant standards: JIS C 2336 ●Dielectric breakdown strength (kV/mm): 45 ●Rated voltage (V): 600 ●Elongation: 180% ●Insulation resistance/volume resistivity: 1.0×106 MΩ･m or more ●Adhesive strength: 1.5N/10mm ●Tensile strength: 30N/10mm ●Operating temperature range: -10 to 90℃ ●Conforms to JIS standards (JIS C 2336) Material/Finish: ●Base material: Polyvinyl chloride resin ●Adhesive: Rubber-based Note: ●This product is not intended for general consumers and therefore does not come with any labels or instruction manuals written or included for general consumers.
