3M Miniature Delta Ribbon Non-Shielded Shell Kit Straight Type 26 Poles 10326-52A0-008 1 S

Catalog number: 10326-52A0-008 Features: ●Industry standard MDR system for half-pitch I/O connectors. ●Identical two-piece structure that combines ease of assembly and robustness. ●Compatible with soldered plugs and normal insulation displacement plugs. ●Two mating and fixing types are available: jackscrew M2.6 type (103XX-52A0) and one-touch type (103XX-52F0), which can be used depending on the application. Applications: ●I/O for FA and general industrial machinery. Specifications: ● Number of poles: 26 ● Color: Black ● Compatible connectors: 101XX-3000 ○○, 101XX-6000 ○○ ● Compatible plugs: 10126-3000PE Material/Finish: ● Shell body: Glass-reinforced polyester ● Cable clamp, cable clamp with ground plate: Stainless steel Set contents/Accessories: ● Shell body: 2 pcs ● Screw M2.6 x 30: 2 pcs (included only with 103XX-52A0) ● Cable clamp: 1 pc ● Cable clamp with ground plate: 1 pc ● Screw M2.6 x 10: 2 pcs ● Nut M2.6: 2 pcs ● Screw M2 x 6: 2 pcs ● Latches: 2 pcs
