3M V-Low Profile Header Right Angle Type 14 Poles 7614-5002 BL 1 Piece

Catalog number: 7614-5002 BL Features: ● 4-sided molding protects the contacts and prevents the socket connector from being inserted in reverse. ● When combined with a board mount socket, it allows board-to-board connection. Applications: ● For connecting boards of general industrial equipment and various units. Specifications: ● Number of poles: 14 ● Color: Gray ● Length (mm): 25 ● Width (mm): 8.5 ● Height (mm): 12.44 ● Compatible socket housing: Socket connector, board mount socket ● Maximum rated current (A): 1A MAX. ● Compatible board thickness: 1.6mm ● Contact gold plating thickness 0.2μm or more (gold flash plating on soldered parts, nickel plating on others) ● RoHS compliant Material/Finish: ● Glass reinforced polyester
