AGENT LB-1000 Lever handle replacement lock B/S100 Partition lock AGLB1000OO 1 S

Catalog number: AGLB1000OO Features: ●Can be replaced from doorknob to lever handle. Ideal for barrier-free access. ●Comes with a luminous sticker that makes it easy to find the key hole even in the dark. ●Comes with a Φ77mm escutcheon that can hide the marks of the previously installed round base. ●Comes with a stopper plate that prevents the lever from turning more than necessary. (L-shaped front, LP, LS backset 100mm only) Applications: ●For office and factory doors. Specifications: ●Color: Silver ●Backset (mm): 100 ●Case depth (mm): 122 ●Compatible door thickness (mm): 25 to 40 ●Type: Partition lock ●Width (mm): 26 ●Length (mm): 110 ●Deadbolt (mm): 15 ●Round seat diameter (mm): 65 ●Mounting screw pitch (mm): 44 ●Partition lock exterior: Lever with emergency unlocking device, interior: Lever with thumb turn ●Front screw pitch (mm): 60, 64, 69.5, 80, 90, 100, 110 ●Finish: Silver painted Material/Finish: ●Lever and round seat: Aluminum die-cast ●Key: Brass (nickel plated) Note: ●Even if the model is compatible, it will not be compatible if the mounting screw pitch is anything other than 44 mm horizontally.
