ARM L-clamp 150mm LD-150 1 piece

Catalog number: LD-150 Features: ● Maximum opening size (mm): 200 ● For use in woodworking, temporary fastening, and gluing work. ● Protective cap prevents damage to the workpiece. Uses: ● For woodworking, gluing, and temporary fastening work. Specifications: ● Total length (mm): 230 ● Maximum opening size (mm): 150 ● Depth (mm): 80 ● Frame dimensions (mm) A: 15.6 ● Frame dimensions (mm) B: 7.5 ● Maximum clamping pressure (kg): 300 ● Clamping pressure (kg) (when opened 30 mm): 300 ● Outer spread width (mm): 150 ● Arm length (mm): 230 ● Mounting hole diameter (mm): 8 ● Maximum opening size (mm): 200 ● Depth of pocket (mm): 80 ● Protective cap included ● Clamping force resistance (kg): 300 Material/Finish: ● Special steel Set contents/Accessories: ● Protective cap Caution: ● Lubricate the screw part from time to time.
