Catalog number: 10-300-2003 Features: *Residual pressure removal function (purge function) prevents accidents caused by hose recoil when disconnected, allowing for safe removal. *Large flow rate and low pressure loss design contributes to energy savings and improved work efficiency. *Simple operation with one touch when connecting, and automatic removal of residual pressure by simply pulling the sleeve when disconnecting. Applications: *For pneumatic tools, pneumatic equipment, and factory air piping *For pneumatic tools, pneumatic equipment, and factory air piping. Specifications: ● Fluid used: Air ● Maximum operating pressure (MPa): 1.6 ● Operating temperature range (℃): -20 to 100 ● Nominal diameter (mm): 5.5 ● Minimum burst pressure (MPa): 14.0 ● Counterpart hose size: 5/16 ● Operating temperature: -20℃ to 100℃ ● Air flow rate: 1050/min (Measured values when inlet pressure is 0.6MPa and pressure loss is 0.05MPa) ● With residual pressure removal function Material/Finish: ● Body: Steel ● Sealing rubber: Nitrile rubber (NBR) Note: ● Can be connected to ARO 210 standard 5.5mm including Series 300.
