Catalog number: 10-310-2005 Features: *Residual pressure removal function (purge function) prevents accidents caused by hose recoil when disconnected, allowing for safe removal. *Large flow rate and low pressure loss design contributes to energy saving and work efficiency. *Simple operation with one touch when connecting, and automatic removal of residual pressure by simply pulling the sleeve when disconnecting. Applications: ● Pneumatic tools, pneumatic equipment, factory air piping Specifications: ● Pressure resistance (MPa): 1.6 ● Mating hose size (inch): 1/2 ● Fluid used: Air ● Maximum operating pressure (MPa): 1.6 ● Operating pressure: 1.6MPa ● Nominal diameter (mm): 5.3 ● Minimum burst pressure (MPa): 14 ● Mating hose size: 1/2 ● Operating temperature: -20 to 100°C ● Air flow rate: 950L/min (Measured values when inlet pressure is 0.6MPa, pressure loss is 0.05MPa) ● With residual pressure removal function Material/Finish: ● Body: Steel ● Sealing rubber: Nitrile rubber (NBR) Note: ● Can be connected to ISO 6150 B, AA 59439, 5.3mm standards including Series 310.
