CEJN Series 320 Nipple NPT1/2 Female Thread 10-320-5405 1 pc

Catalog number: 10-320-5405 Features: ●Large flow rate and low pressure loss design that contributes to energy saving and work efficiency. ●Easy and reliable one-touch connection. ●Small connection with excellent operability, ergonomic design. Applications: ●Pneumatic tools, pneumatic equipment, factory air piping Specifications: ●Pressure resistance (MPa): 1.6 ●Mating side mounting size: NPT1/2 male thread ●Usable fluid: Air ●Maximum operating pressure (MPa): 1.6 ●Operating pressure: 1.6MPa ●Minimum burst pressure (Mpa): 14.0 ●Usable temperature range: -20 to 100°C ●Nominal diameter: 7.6mm ●Air flow rate: 2250L/min (inlet pressure 0.6MPa, pressure loss 0.05MPa, measured value when using the same company's coupling) Material/Finish: ●Body: Steel Note: ●Can be connected to European standard 7.4mm including series 320.
