Catalog number: 10-320-2405 Features: ●Residual pressure removal function (purge function) prevents accidents caused by hose recoil when disconnected, and allows for safe removal. ●Large flow rate and low pressure loss design contributes to energy saving and work efficiency. ●Easy operation with one touch when connecting and automatic removal of residual pressure by simply pulling the sleeve when disconnecting. Applications: ●Pneumatic tools, pneumatic equipment, factory air piping. Specifications: ●Fluid used: Air ●Maximum operating pressure (MPa): 1.6 ●Matching side mounting size: NPT1/2 male thread ●Minimum burst pressure (Mpa): 14.0 ●Air flow rate: 2250L/min (measured value when inlet pressure is 0.6MPa and pressure loss is 0.05MPa) ●Operating temperature range: -20 to 100°C ●Nominal diameter (mm): 7.6 ●With residual pressure removal function Material/Finish: ●Body: Steel ●Seal rubber: Nitrile rubber (NBR) Note: ●Can be connected to European standard 7.4mm including series 320.
