Catalog number: 10-320-2085 Features: ●Safe residual pressure removal function prevents accidents caused by hose recoil when disconnected with simple operation of just pulling the sleeve. ●Large flow rate and low pressure loss design contributes to energy saving and work efficiency. ●Cover protects the surface of surrounding equipment from damage and protects the coupling from impact. Specifications: ●Mating hose size (mm): 11.0 x 16.0 ●Usable fluid: Air ●Maximum operating pressure (MPa): 1.6 ●Minimum burst pressure (Mpa): 14.0 ●Usable temperature range: -20 to 100°C ●Cover to protect against damage ●Nominal diameter (mm): 7.6 ●Air flow rate: 2250L/min (measured value at inlet pressure 0.6MPa, pressure loss 0.05MPa) ●With residual pressure removal function Material/Finish: ●Body: Steel ●Seal rubber: Nitrile rubber (NBR) Note: ●Can be connected to European standard 7.4mm including series 320.
