Catalog number: 19-958-9375 Features: ● The coupling has a residual pressure removal function (purge function) that automatically removes residual pressure, and can be safely removed. ● Polyurethane hose with excellent durability and flexibility. ● It is ready to use as it is already assembled. Applications: ● For pneumatic tools and air work in maintenance factories, paint factories, and general production factories. Specifications: ● Coil diameter (mm): 65 ● Color: Blue ● Hose inner diameter x outer diameter (mm): 8 x 12 ● Usage range (m): 4 ● Total length (mm): 920 ● Coil length (mm): 320 ● Outer diameter (mm): 12 ● Inner diameter (mm): 8 ● Fluid used: Air ● Fluid temperature: -20 to 60 ° C ● Operating pressure: 1.0 MPa ● Connection joint: Coupling / nipple with residual pressure removal function (series 315) Material / Finish: ● Hose: Ester-based polyurethane ● Coupling: Steel Note: ● Compatible with general domestic products.
