Catalog number: 19-911-2183 Features: ● The winding control function gently winds up the hose, preventing danger caused by the hose being unruly. ● The hose guide winds up the hose evenly, preventing the hose from bending when stored. ● The hose can be easily replaced without disassembly. ● Easy to install with one touch, making installation and maintenance easy. ● The patented large flow design contributes to improving work efficiency. ● Comes with a CE mark in accordance with 2006/42/EC. ● The safe residual pressure removal function prevents accidents caused by hose recoil when separated (only with eSafe coupling). ● Residual pressure is automatically removed when separated. ● The connection fittings (primary side/secondary side) are compatible with general domestic products. Applications: ● For air work in automobile repair shops, paint shops, and general production factories. Specifications: ● Hose inner diameter x outer diameter (mm): 8.0 x 12.0 ● Total hose length (m): 17 ● Primary installation side: Nipple ● Secondary installation side: 315 eSafe coupling ● Primary hose length (m): 1.5 ● Secondary hose length (m): 17 ● Maximum operating pressure (MPa): 1.6 ● Operating pressure (MPa): 1.6 ● Width (mm): 490 ● Depth (mm): 190 ● Height (mm): 409 ● Outer diameter (mm): 12.0 ● Inner diameter (mm): 8.0 ● Color: Blue ● Total length (m): 17 ● Connection fitting: 315 eSafe coupling / nipple ● Fluid used: Air ● Operating temperature range (℃): -20 to 60 ● Automatic retraction type ● Ratchet type stopper ● Hose color: Blue Material / Finish: ● Main body cover: Plastic ● Hose: Braided polyurethane Note: ● Connection fittings (primary side / secondary side) are compatible with general domestic products.
