Catalog number: F4000-15-WF Features: ● Efficiently removes dust and water droplets from air piping. ● The element used has a unique chemical fiber structure that is rough on the surface and becomes finer toward the inside. ● It significantly reduces clogging and significantly increases the life of the element. Applications: ● Removal of dust and drainage from air piping Specifications: ● Filtration accuracy (μm): 5 ● Operating pressure (MPa): 1 ● Processing air flow rate (［［M3］］/min): 3.0 ● Connection port size: Rc1/2 ● Overall length (mm): 193.5 ● Overall width (mm): 80 ● Drain discharge method: Manual auto drain (NO type) ● Used fluid: Air ● Fluid temperature (℃): 5 to 60 ● Used fluid: Air ● Fluid temperature: 5 to 60℃ ● Drain discharge method: Auto drain Note: ● For the F3000 to 8000-WF series, the minimum operating pressure of the auto drain is 0.1MPa. Air is purged together with the initial drainage until the pressure rises to 0.1 MPa.
