CKD Silencer Resin Body Type SLW-6S 1 pc

Catalog number: SLW-6S Features: ●A device that reduces exhaust noise generated by exhaust air. ●Compact and lightweight type with a noise reduction effect of 25 dB or more. Applications: ●For silencing exhaust air from the exhaust port of a directional control valve. Specifications: ● Sound reduction (dB): 25 or more ● Effective cross-sectional area (mm2): 12 ● Connection diameter: R1/8 ● Overall length (mm): 22.0 ● Operating pressure (MPa): 0 to 1.0 ● Operating temperature (℃): -10 to 60 (but do not freeze) ● Fluid used: Compressed air ● Width (mm): 10.5 ● Fluid temperature (℃): 5 to 60 ● Ambient temperature (℃): -10 to 60 ● Fluid used: Compressed air ● Sound reduction effect: 25dB or more ● Flow rate: 800L/min (ANR) (effective cross-sectional area: 12mm2) ● Applicable cylinder tube inner diameter: φ20 to 80mm (reference) Material/Finish: ● Body: PP SLW-6S, 8S/SLW-20S are polyamide resin ● Element: PP sintered resin Note: ● The fluid temperature and ambient temperature must not freeze, but depending on the air quality (dew point), freezing may occur due to adiabatic expansion. ● The flow rate is the atmospheric pressure converted value at a pressure of 0.5 MPa.
