CKD Shock Killer Basic Type NCK-00-0.3 1 pc

Catalog number: NCK-00-0.3 Features: ●An impact buffer device ideal for stopping workpieces with thrust at low and medium speeds. ●Compact yet has large absorbed energy, and is highly space-efficient. ●Simple installation. ●The structure uses a slit orifice method, which was previously considered difficult, to achieve high absorption capacity at low speeds and linear soft stopping. Applications: ●As an impact buffer device when stopping workpieces. Specifications: ●Stroke (mm): 6 ●Impact speed (m/s): 1.5 ●Thread size: M8 x 0.75 ●Type: Basic type ●Maximum absorbed energy (J): 3 ●Ambient temperature -10 to 80°C ●Maximum impact speed 1.5 m/s Caution: ●The shock killer's absorption capacity changes depending on the speed and ambient temperature.
