CKD Cylinder Switch T Series Contact 2-Wire Type SW-T0H3 1 pc

Catalog number: SW-T0H3 Features: ● A general-purpose cylinder switch that can be installed on many cylinders. Applications: ● For detecting the position of pneumatic cylinders. ● For programmable controllers and relays. Specifications: ● Lead wire outlet: Straight ● Load voltage (V): DC12/24, AC110 ● Lead wire length (m): 3 ● Indicator light: Red ● Internal voltage drop (V): 3 or less (for DC, when load current is 30 mA) ● Leakage current (mA): 0 ● Applicable cylinders: Standard type (CAC4/CKV2/CMA2/CMK2/HCM/JSC3/JSC4/JSG/JSK2/JSM2/LCG/LCR/LCW/LCX/MRG2/MRL2/RCC2/RCS2/RRC/SCA2/SCG/ SCM/SCP※3/SCS2/SRM3/SSD/SSD2/SSG/STG/STS/STL/STK/UCA2/UCAC2/ULK/Hand/Chuck)●2-wire contact type●1-color display type●Lead wire extraction direction: straight type●Lead wire: oil-resistant vinyl cabtyre cord●Load current: 5 to 50mA (load voltage: DC12/24V), 7 to 20mA (load voltage: AC110V)●Indicator light: red LED (lights up when ON)●Protection structure: IEC standard IP67, JIS C0920 (waterproof), oil resistant●Ambient temperature: -10 to 60°C Caution:●Contact protection measures may be necessary depending on the conditions of use (please check the manufacturer's catalog for details).
