CKD Super Mount Cylinder SMG-L-10-30 1 piece

Catalog number: SMG-L-10-30 Features: ●By integrating the mounting block, space saving and weight reduction have been achieved. ●Direct installation is possible from 5 sides. ●Even with a cylinder switch attached, there is almost no protrusion, making it neat and flat. ●Improved maintenance of packing replacement. Specifications: ●Tube inner diameter (mm): 10 ●Stroke (mm): 30 ●Piping port size: M5 ●Mounting support type: Direct mounting ●Tube inner diameter (Φ): 10 ●Double acting, single rod type ●Operating fluid: Compressed air ●Operating pressure range: 0.12 to 0.7 MPa (Φ6 mm), 0.06 to 0.7 MPa (φ10 to 16 mm), 0.05 to 0.7 MPa (φ20 to 25 mm) ●Ambient temperature: -10 to 60°C (but not frozen) ●Cylinder switch magnet: Yes (cylinder switch can be installed later) ●Cushion: With rubber cushion ●Rod tip: Male thread
