CKD Tube Fittings New Joint Straight Type Suitable for Tube Outer Diameter 4mm Connection Port Size M3 GWS4-M3-S 1 pc

Catalog number: GWS4-M3-S Features: ●Flame-retardant resin (equivalent to UL-94 standard V-0) standard + nickel plating on brass + sealant applied to threads as standard Application: ●Straight tube with one end + male thread Specifications: ●Compatible tube outer diameter (mm): 4 ●Connection port size: M3 x 0.5 ●Maximum operating pressure (MPa): 1.0 ●Fluid temperature (℃): -10 to 60 (no freezing) ●Total length (mm): 16.9 ●Operating pressure: -100 kPa to 1.0 MPa ●Operating fluid: Compressed air ●Compatible tube outer diameter D (mm): 4 ●Operating pressure range: -100 kPa to 1.0 MPa ●Y-shaped plug + tube Material/Finish: ●Body: Brass (electroless nickel plating) + Polybutylene terephthalate (PBT) ●Seal rubber: Nitrile rubber
