CKD Tube Fitting New Joint Threadless Compatible with Tube Outer Diameter 4mm/6mm GWP46-0 1 pc

Catalog number: GWP46-0 Features: ●Flame-retardant resin (equivalent to UL-94 standard V-0) standard + nickel plating on brass + sealant applied to threads as standard Application: ●Plug Specifications: ●Compatible tube outer diameter D1 (mm): Φ6 plug ●Maximum operating pressure (MPa): 1.0 ●Operating temperature range (℃): -10 to 60 (no freezing) ●Compatible tube outer diameter D2 (mm): Φ4 plug ●Operating pressure: -100kPa to 1.0MPa ●Operating fluid: Compressed air ●Fluid temperature (℃): -10 to 60℃ (no freezing) ●Maximum operating pressure: 1.0MPa ●Fluid temperature (℃): -10 to 60℃ (no freezing) ●Y-shaped plug + tube Material/Finish: ●Polybutylene terephthalate (PBT)
