CKD New Joint Screwless GWP10-0 1 pc

Catalog number: GWP10-0 Features: ●Flame-retardant resin (equivalent to UL-94 standard V-0) standard + nickel plating on brass + sealant applied to threads as standard Application: ●Plug Specifications: ●Applicable tube outer diameter D1 (mm): 10 ●Maximum operating pressure (MPa): 1 ●Operating pressure: -100 kPa to 1.0 MPa ●Operating fluid: Compressed air ●Fluid temperature (℃): -10 to 60 (no freezing) ●Connection joint diameter D (mm): 8 x 8 ●Operating pressure range: -100 kPa to 1.0 MPa ●Fluid temperature: -10 to 60℃ (no freezing) ●Y-shaped plug + tube Material/Finish: ●Polybutylene terephthalate (PBT)
