Catalogue number: L1000-6-W Features: ● Supplies fine oil mist to pneumatic equipment. ● Oil supply can be performed even when pressurized by removing the fill plug and releasing the pressure inside the bowl. ● Lightweight and compact type. ● Set after the regulator. Specifications: ● Operating pressure (MPa): 1 ● Processing air flow rate (［［M3］］/min): 0.55 ● Oil storage capacity (［［CM3］］): 20 ● Connection diameter: Rc1/8 ● Overall length (mm): 133.0 ● Overall width (mm): 40 ● Fluid used: Air ● Fluid temperature: 5 to 60°C ● Oil used: Type 1 turbine oil (equivalent to ISO VG#32)
