Catalogue number: L4000-10-W Features: ● Supplies fine oil mist to pneumatic equipment. ● Oil supply can be performed even when pressurized by removing the fill plug and releasing the pressure inside the bowl. ● Lightweight and compact type. ● Set after the regulator. Specifications: ● Operating pressure (MPa): 1 ● Processing air flow rate (［［m3］］/min): 1.7 ● Oil storage capacity (［［cm3］］): 170 ● Connection diameter: Rc3/8 ● Overall length (mm): 196.0 ● Overall width (mm): 80 ● Fluid used: Air ● Fluid temperature: 5 to 60°C ● Oil used: Type 1 turbine oil (equivalent to ISO VG#32)
