Catalogue number: L8000-25-W Features: ● Supplies fine oil mist to pneumatic equipment. ● Oil supply can be performed even when pressurized by removing the fill plug and releasing the pressure inside the bowl. ● Lightweight and compact type. ● Set after the regulator. Specifications: ● Operating pressure (MPa): 1 ● Processing air flow rate (［［M3］］/min): 10.0 ● Oil storage capacity (［［CM3］］): 170 ● Connection diameter: Rc1 ● Overall length (mm): 282.0 ● Overall width (mm): 100 ● Fluid used: Air ● Fluid temperature (℃): 5 to 60℃ ● Oil used: Type 1 turbine oil (equivalent to ISO VG#32)
