CKD Outdoor Product W Series Silencer Metal Body Type SL-8A-W 1 pc

Catalog number: SL-8A-W Features: ●Metal body type silencer that reduces exhaust noise generated by exhaust air. ●All series are unified in lightweight and compact size. ●Element can be replaced for long life (model: SL-8A-EL). ●Can be used outdoors. Applications: ●For silencing exhaust air from the exhaust port of directional control valves. Specifications: ● Sound reduction (dB): 20 or more ● Effective cross-sectional area (mm2): 36 ● Connection diameter: R1/4 ● Overall length (mm): 64 ● Operating pressure (MPa): 0 to 0.9 ● Operating temperature (℃): -10 to 60 (but do not freeze) ● Fluid used: Compressed air ● Fluid temperature (℃): 5 to 60 ● Pressure resistance (MPa): 1.35 ● Ambient temperature (℃): -10 to 60 ● Noise reduction effect (dB): 20 or more ● Fluid used: Compressed air ● Flow rate: 2400L/min (effective cross-sectional area: 36mm2) ● Reference applicable cylinder tube inner diameter: φ50 to φ100mm Material/Finish: ● Body: Aluminum ● Element: Vinylidene chloride Caution: ● Ambient temperature: Do not freeze. ● Flow rate is the atmospheric pressure equivalent value at a pressure of 0.5MPa.
