CKD Outdoor Product W Series Speed ​​Controller Medium Diameter Type SC1-10-W 1 pc

Catalog number: SC1-10-W Features: ●Can be used outdoors. ●Medium-diameter inline speed controller. ●Adjustment knob has a lock. Applications: ●For adjusting the speed of air cylinders. Specifications: ● Connection port size: Rc3/8 ● Operating pressure (MPa): 0.05-1.0 ● Fluid used: Compressed air ● Fluid temperature (℃): 5-60 ● Pressure resistance (MPa): 1.5 ● Ambient temperature (℃): -10-60 ● Applicable cylinder tube inner diameter (mm): 50-140 ● Fluid used: Compressed air ● Connection type: Inline (threaded) ● Flow type: Standard flow rate ● Free flow rate: 2600L/min (effective cross-sectional area: 39mm2) ● Controlled flow rate: 1500L/min (effective cross-sectional area: 22mm2) ● Reference applicable cylinder tube inner diameter: φ50-φ140mm ● Needle rotation number: 10 times ● Meter-in type Material/Finish: ● Metal parts: Aluminum alloy die-cast, stainless steel, brass ● Packing part: Fluorine rubber Caution: ● Fluid temperature/ambient temperature: No freezing. ● Please note that depending on the air quality (dew point), there is a risk of freezing due to adiabatic expansion. ●The flow rate is the atmospheric pressure equivalent value at a pressure of 0.5 MPa. ●This product is for outdoor use, but please refer to the manufacturer's catalog for information on the usage environment. ●All brass parts are electroless nickel plated.
