Catalogue number: PKA-04-27-AC200V Features: ● Solenoid valve for general fluids (for air). ● A wide range of models are available in terms of fluids, pressures, and apertures. Specifications: ● Effective cross-sectional area (mm2): 100 ● Connection aperture: Rc1/2 ● Operation method: Pilot kick type ● Power supply (V): AC200 ● Number of ports: 2 ● Operating pressure (MPa): 0 to 0.7 ● Fluid used: Air ● Fluid temperature (℃): 5 to 60 ● Sonic conductance (C [dm3/(S・bar)]): 20 ● Orifice (mm2): 15 ● Operating pressure: 0 to 0.7MPa
