Catalog number: PKA-10-27-AC100V Features: ● Solenoid valve for general fluids (for air). ● A wide range of models are available in terms of fluids, pressures, and calibers. Specifications: ● Effective cross-sectional area (mm2): 220 ● Connection caliber: Rc1 ● Operation method: Pilot kick type ● Power supply (V): AC100 ● Number of ports: 2 ● Operating pressure (MPa): 0 to 0.7 ● Fluid used: Air ● Fluid temperature (℃): 5 to 60 ● Orifice (mm squared): 25 ● Operating pressure: 0 to 0.7MPa
