CKD(株)
CKD Air pilot kick type 2-port solenoid valve Rc3/4 AC200V PKA-06-27-AC200V 1 unit
CKD Air pilot kick type 2-port solenoid valve Rc3/4 AC200V PKA-06-27-AC200V 1 unit
Regular price
¥18,005
Regular price
Sale price
¥18,005
Unit price
/
per
Shipping calculated at checkout.
Couldn't load pickup availability
Catalog number: PKA-06-27-AC200V Features: ● Solenoid valve for general fluids (for air). ● A wide range of models are available in terms of fluids, pressures, and apertures. Specifications: ● Effective cross-sectional area (mm2): 128 ● Connection aperture: Rc3/4 ● Operation method: Pilot kick type ● Power supply (V): AC200 ● Number of ports: 2 ● Operating pressure (MPa): 0-0.7 ● Fluid used: Air ● Fluid temperature (℃): 5-60 ● Orifice (mm2): 20 ● Operating pressure: 0-0.7MPa
