CKD Air pilot type 2-port solenoid valve PVS-15A-210-AC200V 1 unit

Catalog number: PVS-15A-210-AC200V Features: ● Solenoid valve for general fluids. ● A wide range of models are available in terms of fluid, pressure, and caliber. Applications: ● For air, water, and steam. Specifications: ● Effective cross-sectional area (mm2): 55 ● Connection caliber: Rc1/2 ● Operation method: Electric ● Power supply (V): AC200 ● Number of ports: 2 ● Operating pressure (MPa): 0.05-1 ● Fluid used: Steam, water, air ● Fluid temperature (℃): 5-185 ● Cv value: 3.1 ● Orifice diameter (mm): 15 ● Operating pressure difference (MPa): 0.05-1 ● Fluid temperature: 5-185℃ ● Operating pressure difference: 0.05-1MPa
