CKD(株)
CKD Air pilot type 2-port solenoid valve PVS-20A-210-AC200V 1 unit
CKD Air pilot type 2-port solenoid valve PVS-20A-210-AC200V 1 unit
Regular price
¥26,572
Regular price
Sale price
¥26,572
Unit price
/
per
Shipping calculated at checkout.
Couldn't load pickup availability
Catalog number: PVS-20A-210-AC200V Features: ● Solenoid valve for general fluids. ● A wide range of models are available in terms of fluid, pressure, and caliber. Applications: ● For air, water, and steam. Specifications: ● Effective cross-sectional area (mm2): 96 ● Connection caliber: Rc3/4 ● Operation method: Electric ● Power supply (V): AC200 ● Number of ports: 2 ● Operating pressure (MPa): 0.05-1 ● Fluid used: Steam, water, air ● Fluid temperature (℃): 5-185 ● Cv value: 5.4 ● Orifice diameter (mm): 20 ● Operating pressure difference (MPa): 0.05-1 ● Fluid temperature: 5-185℃ ● Operating pressure difference: 0.05-1MPa
